GENERAL
Dimensions (WxDxH) 14.9 in x 5.6 in x 15.9 in
Display Type LCD monitor / TFT active matrix
Native Resolution 1280 x 1024 at 75 Hz
Contrast Ratio 400:1
Aspect Ratio: 5:4
Controls & Adjustments Brightness, contrast
Horizontal Viewing Angle +70 / -70
OSD Languages English, German, French, Spanish, Japanese
Vertical Viewing Angle +60 / -60
Viewable Size 17"
Pixel Pitch 0.264 mm
Brightness 250 cd/m²
Screen Coating Anti-glare, hard coating
Horizontal Refresh Rate 80 kHz
Vertical Refresh Rate 76 Hz
ManufacturerDell, Inc.
CONNECTIVITY
Interfaces 1 x VGA - 15 pin HD D-Sub (HD-15)
POWER DEVICE
Nominal Voltage AC 120/230 V
Frequency Required 50/60 Hz
Power Consumption Operational 40 Watt
DISPLAY
Image Brightness 250 cd/m2
Image Contrast Ratio 400:1
Type LCD monitor
MISCELLANEOUS
OSD Languages English, French, German, Japanese, Spanish
Controls & Adjustments brightness, contrast
INTERFACE PROVIDED
Qty 1
Connector Type 15 pin HD D-Sub (HD-15)
VIDEO
Video Output none
ENVIRONMENTAL STANDARDS
ENERGY STAR Certified Yes
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 41 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 80%
DIMENSIONS & WEIGHT
Width 14.9 in
Depth 5.6 in
Height 15.9 in
HEADER
Brand Dell
Product Line Dell
Model E172FP
Packaged Quantity 1
Compatibility PC
PROJECTOR
Max V-Sync Rate 76 Hz
Max H-Sync Rate 80 Hz
TV TUNER
TV Tuner Presence No
GENERAL
Manufacturer Dell, Inc.
